Commercial double door 72 x 80
The commercial double door 72 x 80 adopts a detachable steel door frame. It is equipped with a commercial-grade export device and imported decorative setting, two 4 inches. x 4 inches. Heavy-duty spring hinges and a 4 inch. x 4 inches. Heavy-duty commercial hinges. The fire rating of the door and frame components is 1-1/2 hours. The door panel and door frame are made of galvanized steel plate to ensure good paint adhesion. The frame is compatible with stud walls with a thickness of 4-7/8 inches. And can be constructed with gypsum board while the walls are being built. The frame provides compression anchors and 2 sets of strap anchors for drywall applications.
FEATURES | DOOR OPTIONS FOR FIRE RATING | ||
UP to 3 hour fire UL label | Core selections: | Variety: | |
Includes some doors with ites | Honeycomb core | Sound Transmission Control(STC) | |
Fire life glass.Wire grass | Polystyrene core | Stainless steel doors | |
Fire rated life frame avaliable | Mineral fireboard core | Temperature rise doors | |
Brand | Golden House (GH) | ||
Standard | UL 10(b),UL 10(c) | ||
Certifications | INTERTEK(WHI),FM,UL | ||
Fire rated time | 45min,90min,up to 180 min | ||
Door Size (single) | Width not beyond 1200mm Height not beyond 2800mm | ||
Leaf thickness:45mm | |||
Frame depth:100-300mm | |||
Door size (Double) | Maximum size is 8'x8'(2400x2400mm) | ||
Door leaf sheet | 20Ga-18Ga (1.0/1.2mm) | ||
Door frame sheet | 16Ga.(1.5mm) | ||
Opening | Left hand,Right hand,Left hand reverse,Right hand reverse(90 degree) | ||
Type | 2panel/6panel/flush panel/vision/louver/glass | ||
Material of leaf and frame | CRS or Galvanized Steel or Galvannealed Steel | ||
Filling material | Honeycomb,Polystyrene,Mineral Fire Board | ||
Surface finish | Primer paint/finsih paint/power coated/print transfer | ||
Color | RAL color system or be customized as well | ||
Application | Suitable for building project,business,home decoration(Office,hotle,church,home and so on ) | ||
Packing | in wooden or steel pallet with hand box package | ||
Accessories | Hinges | UL listed ball bearing or spring hinges | |
Lock | UL cylinder,mortise,panic bar,magnetic lock | ||
Handle | Brushed finishing,SS201,SS304 ,SS316 | ||
Rubber seal | Foreproof rubber seal | ||
Door closer | UL listed closer,concealed closer | ||
Glass/Vision | UL listed wire glass or tempered glass | ||
Louver | Louver/fire rated louver | ||
Other hardwares | Customized | ||
FAQ
Q1: Where is your factory?
Our factory locates in Dalian, north of China, one hour flight from Beijing; it is sea port city. We are manufacturer on fire rated doors, wood door and metal door.
Q2: How can we control the quality before we get the goods?
A reliable quality inspection team tests the products in each process, from material purchase to package, we can show you video or pictures during the inspection.After shipping, we can give you quality guarantee.
Q3. MOQ
Normally one 20 feet container(160-180sets); if just test our quality before mass order placed, then the minimum qtys is 10sets.
Q4: How to order(payment term;shipping;Delivery time)?
A: Payment Term: T/T; L/C
Shipping: express for sample,sea shipment for bulk order.
Delivery time: About 20-35days.
First we need know your specific door request and specs, then we issue the related solutions to meet your requirements. After that, we make the invoice and drawings for your approval. Once you approve the both, 50% deposit will be arranged and the production is started; after the order is finished, we take video or pictures to you, or you dispatch inspector here, then collect the balance before shipping.
Q5:Do u have stock?
we stock American standard anti panic metal door & frames as procedure in factory. When your order is special and need customerized , we need arrange that specially, just like project schedule, most of them need customerized by specific size, color, lock type, materials, etc. So, we can pick up wholesaler order or end user project order both.
