fire wooden door for Hospital feature：
All wood fire door and frames comply with SDI american standards.
20mins 45mins 90mins or more fire rated time label(UL ,WHI).
MDF board+natrual veneer or enigneered veneer or laminated melamine finished.
perlite mineral fireboard filling core with stronger fireproof grade.
Surface treatment be primer or lacquer painting or half full sealed painting.
Door comes pre-drilled and mortised for added convenience
Steel metal jamb frame or wodden Frame (HDF+LVB+MDF) with melamine fiish or natrual veneer.
Knock-down shipment or pre-hung shipment is possible.
fire wooden door for Hospital Technical Date：
| Standard Size | Door leaf height: 1780mm-2400mm Door leaf width: 600mm-1000mm Door leaf thickness: /45mm/55mm Wall thickness: 100mm-300mm or can be customized |
| Surface Treatment | Primer finished /wood veneer painting /heat transfer + printing /wood stained painting; multi-layers full-sealed painting finished |
| Type | Interior door |
| Leaf Pattern Design | with same wood grain pattern or flush door or groove pattern or classical molded pattern or laminated door or metal line decoration doors |
| Vison Panel | louver or wireglass customized |
| Material | HDF/MDF Panel thickness 5mm/6mm/8mm/12mm available |
| Leaf Structure | solid wood or MDF board + inner filling core perlite mineral fireboard |
| Certification | UL WHI approval |
| Frame or Jamb Structure | metal steel frame or Solid wood frame painting . |
| Veneer Color | black walnut,cherry,white,oak,mahogany or can be customized any color |
Fire-Rated doors are required to be suited for the various type of walls as below :
Frame and Hardware must also carry the appropriate fire label
| Door fire Rating | Wall Rating | Description and Use |
| 3 Hour | 4 Hour | The openings are in wall that separating buildings or dividing a single building into designated fire areas.doors for this openning are required at 3 hours fire rating. |
| 1-1/2 Hour | 2 Hour | Openings are used in enclosures of vertical communication or egress through buildings. theste could be stairwells or elevator shafts. They also are in boiler rooms and in exterior walls that have the potential for severe fire exposure from the outside of the building. |
3/4 Hour (45 Minutes) | 1 Hour | For use on the openings are in corridors and room partitions. A door with this rating may also be used in the exterior wall which are subject to moderate fire exposure from the outside of the building. |
1/3 Hour (20 Minutes) | 1 Hour | These openings are in corridors or interior partitions where this fire rating is required . |
Solid wooden frame:
GH offers a complere line of non-fire rated and fire rated wooden frames with similar design appearance.
Available in knock down frame and pre-hung frame.
Material have fireproof plywood with wood veneer.
Flush wood veneer, the structure is consist of MDF/ptywood with veneer, stile and rail, solid wood
edge, chipboard or mineral fireboard to be inside core, and it can be primer paint or stained painting finish.High pressure decorative laminate door
Min frame width:100mm Max frame width:equal to wall thickness
Fire rating up to 20mins with UL listed
Hollow metal frame:
Frames are manufactured to accommodate any wall condition, including masonry frameand drywall frame type. A wide variety of frame anchors are available. Width up to andincluding 4'0", height up to and including 8'0"
Available in knock down frame and welded frame
Material have cold roller or galvanized steel
Steel thickness have 16ga. 14ga
Surface painting can match with wooden door color
Fire rating from 45mins to 180mins with WHI listed
1991--Golden house started production of metal and wood fire door.
1998-- expanded production plant , a large production line covering area is 1, 200,000 sq.
2003—imported German solid wood and metal door production line.
2006--become the first factory who possesses INTERTEK WH and UL FM fire certificates.
2007--Set up a distribution center with big warehouse containing 6000 doors in Los Angeles USA.
2012--Set up a distribution center with warehouse containng 5000 doors in Vancouver Canada.
2015--Authorized WHI fire label with fire-rated 3 hours on double steel door and UL fire label with fire-rated 20 minutes on wooden door.
2018--Authorized UL fire label with fire-rated 90 minutes on steel doors.
2019--Authorized WHI fire label with fire-rated 90 minutes on wooden door matched steel frame.
2020--Authorized UL fire label with fire-rated 3 hours on steel door and frame.
2021--Authorized the 34dB sound insulation steel door certificate.
2022--Fire Door Glass Light Frames holder is UL certified
Hot Tags: fire wooden door for hospital, China fire wooden door for hospital suppliers, manufacturers, factory, wood door in varnished buildings, wood door case studies, rabbeted wood door, wood door lock, light wood door, wood door lead time
